Shelf capacity 9.1m2 on 9 shelves
Performance ice test 100kg ice sublimated in sub 24 hrs
Average yield of dry product per cycle 20 kg based on 100 kg wet product @ 80% moisture
Potential heat energy recovery 12 kW
Peak power requirement 35kW, 50 or 60 Hz
Est. Energy consumption 2.4 kWh / kg
Est. Typical operational power consumption (Dry) 10 kW

Ice condenser capacity 100kg
Ice condenser temperature -55⁰C
Shelf temperature range -35⁰C to 70⁰C
Shelf spacing (mm) 35mm
Product tray material Food grade anodised aluminium
Number of product trays 18 per cycle (2 sets supplied)
Heating / cooling medium Temper 55
Number of doors on product chamber 1
Plant equipment Plant housed underneath chamber

Overall footprint 3.44m (L) x 1.40m (W) x 1.94m (H)
Weight 2,500 kg
Product trays size 1025mm x 495mm x 20mm
