Shelf capacity 113.7m2 on 19 shelves
Performance ice test 1200kg ice sublimated in sub 24 hrs
Average yield of dry product per cycle 240 kg based on 1200 kg wet product @ 80% moisture
Potential heat energy recovery 110 kW
Peak power requirement 180kW, 50 or 60 Hz
Est. Energy consumption 1.7 kWh / kg
Est. Typical operational power consumption (Dry) 84 kW

Ice condenser capacity 1200kg
Ice condenser temperature -55⁰C
Shelf temperature range -35⁰C to 70⁰C
Shelf spacing (mm) 35mm
Product tray material Food grade anodised aluminium
Number of product trays 224 per cycle (2 sets supplied)
Heating / cooling medium Temper 55
Number of doors on product chamber 2 (one on each end)
Plant equipment Plant on separate skid

Chamber Footprint 5.12m (L) x 2.80m (W) x 2.58m (H)
Plant skid footprint 5.22m (L) x 2.00m (W) x 2.35m (H)
Weight 18,200 kg
Product trays size 1025mm x 495mm x 20mm
